ETABS

Structural Software for Building Analysis and Design

starstarstarstarstar_half 4.9 (154 ratings)

5576 learners enrolled

Language: English

Instructors: Anjaneya Puli

  Enroll in Course

Reviews

4.9
star star star star star_half
people 154 total
5

143
4

10
3

0
2

0
1

1

Why this course?

Description

ETABS for Civil Engineers
About this course
Application uses of ETABS Software
Description
This Course is designed for easy learning of ETABS Software for Civil Engineering Professional/Students who are interested in Structural Analyses and Design.

What you’ll learn in this course?

Concepts of Structure, Loads ,Analyses, Reactions & Design, ETABS and its application, How to use ETABS for the Structural Analyses and Design, Creating and Defining projects, Creating Structural geometry, Applying section properties, supports, loads,load combinations, analyzing the structure, Finding reactions, Applying ISCodes,Designing the structure, Creating reports.

Are there any course requirements or prerequisites?

Basic Structural Analyses and Design.

Knowledge of Standard building codes of respective country

Who this course is for:

Civil Engineering Students/Professional, Structural Engineering Graduate, Structural consultants and Site Supervisors.

COURSE CONTENT

Introduction to ETABS

Launching ETABS, Graphical user interface, Opening a new project, save the project, Save As the Project, Code setting, Unit Setting, Opening the One-Two-Three-Four Windows, Closing the Windows, Active Window ,Display Theme, Exiting the File.

Grid System

Understanding the Default Grid, Set Plan View, Elevation View, 3D View. Editing & Creating new grids, Grid color, and Editing, Bubble location and Size, Adding and Deleting stories. Hide grid lines, Show Grid lines.

Material Properties:

Changing the Unit to N-MM, Editing the Default Material, Creating the Name Material (M25, M30), Specify Concrete Comp Strength, Specify Yield Stress of Bending Reinforcement, Specify Yield Stress of Shear Reinforcement.

Section Properties:

Defining Frame sections: Rectangular Columns, Circular Columns, Rectangular Beams, and Specify Cover to the Columns & Beams.

Wall & Slab Sections: Create wall section, Create One way slab, Create Two way slab.

Draw Line & Area Objects:

Draw Line Objects: Draw Lines, Create Lines in Region, Create Columns in Region, And Create Secondary Beams.

Draw Area Objects: Draw Areas, Create Rectangular Areas, Draw areas at Click, Draw Walls, and Create Walls in Region, Draw Doors, and Draw Windows.

Editing Objects:

Join Lines, Divide Lines, Mesh Areas, Merge Areas, Expand Areas, Shrink Areas, Extrude Points to Lines, and Extrude Lines to Areas, Move Points, Lines, and Areas.

Replicate: Linear, Radial, Mirror, Story.

Selection:

Select at Point, Window, On Plane, By Frame section, By wall section, By slab section, By line type, By area type, By story level, Invert selection, Deselect, Get Previous selection, Clear selection, Create Group, Select by Groups.

Supports: Fixed supports, simply support, roller support, pin support.

Loads:

Point load: Add to existing loads replace existing loads, delete existing loads.

Frame/line load: Point load on frame, Distribution load, Trapezoidal load, Linearly varying loads.

Shell/ area: Dead load on slab, Live load on slab.

Show loads: Joint /point load, frame/line load, shell/ area load.



Static load cases: IS1893-2002 : EQX,EQY,

IS875-1987: WLX, WLY, Modify lateral loads.

Load combination:

Manual load combinations: load combinations without facts of safety, load combinations with factor of safety.

Automatic load combinations: Add default design combination as per concrete frame design.

ANALYSIS: Check model, Run Analysis,

Show un-deformed shape, show deformed shape, show support reactions, Axial forces, shear forces, bending moment, shell stresses.

Show tables: Model Definition, analysis result. Unlock and lock the material.

Concrete Frame Design:

Select design code: IS456-2000, Select design load combinations, start design, display design result.

Longitudinal reinforcing, rebar percentage, shear reinforcing, column P-M-M Intersection ratios, Beam/ column capacity ratios, column/Beam capacity ratios.

Print: print setup, print graphics, print tables, capture DXF file, capture pictures, and create a video.

Import-export: Import AutoCAD file into ETABS, Export ETABS file into AutoCAD



How to Use

After successful purchase, this item would be added to your courses.You can access your courses in the following ways :

  • From the computer, you can access your courses after successful login
  • For other devices, you can access your library using this web app through browser of your device.
